Rotary Coating Machine

A rotary coating machine is used for coating compound fertilizers, effectively preventing clumping and improving fertilizer quality and storage stability. This equipment plays a vital role in fertilizer production and can meet the needs of large-scale production. It primarily consists of a screw conveyor, a mixing tank, an oil pump, and a main unit. It utilizes either a powder coating or liquid coating process. The main unit is typically lined with polypropylene or acid-resistant stainless steel to ensure corrosion resistance and longevity.

CONTACT US

+
PREV Fertilizer Batching Scale NEXT No next article
  • SPECIFICATIONS
  • CONTACT US

  • The rotary coating machine operates by using a main motor to drive a belt and pulley, which is then transmitted to a drive shaft via a speed reducer. Split gears mounted on the drive shaft mesh with a large ring gear fixed to the machine body, operating in opposite directions. Material is added at the feed end, mixed within the drum, and discharged through the discharge port.
